Part no.: U3-BPS-50-40-A
brake band piston kit (servo)
Bigger picture
In stock
Genuine used
Genuine used
Identification
AW50-40LN, AF22 - AW50-40LE - used part, no warranty
AW50-40LN, AF22 - AW50-40LE - used part, no warranty
piston cover outer diameter 48,2 mm, piston outer diameter 46,5 mm, shaft length 70,45 mm (2 grooves)
used part - quality: signs of use, item might need some work on it - can be ordered only if in stock - subject unsold
If bearings, seals, gaskets and washers are supplied they are f.o.c. as they might need to be changed - missing or damaged items of this kind will not be replaced by us.
All used parts are sold with no warranty
It is possible that various executions of brake band piston are available for AW50-40/AW50-42 transmissions - PLEASE CHECK CAREFULLY BEFORE INSTALLATION. WE WILL NOT TAKE RESPONSIBILITY FOR DAMAGES RESULTING FROM THE INSTALLATION OF A WRONG SPARE PART/COMPONENT. Major differences could be length of shaft and grooves on shaft,
used part - quality: signs of use, item might need some work on it - can be ordered only if in stock - subject unsold
If bearings, seals, gaskets and washers are supplied they are f.o.c. as they might need to be changed - missing or damaged items of this kind will not be replaced by us.
All used parts are sold with no warranty
It is possible that various executions of brake band piston are available for AW50-40/AW50-42 transmissions - PLEASE CHECK CAREFULLY BEFORE INSTALLATION. WE WILL NOT TAKE RESPONSIBILITY FOR DAMAGES RESULTING FROM THE INSTALLATION OF A WRONG SPARE PART/COMPONENT. Major differences could be length of shaft and grooves on shaft,
B4 brake
1
AW50-40LN, AF22 - AW50-40LE
